Linear Voltage Regulator/Voltage Reference: Low Dropout Linear Regulator; Ultra Low Dropout Linear Regulator; DDR Regulator; Voltage Reference
DC/DC Converter for High Power Application: HV Step Down Series; Buck-Boost Series
DC/DC Converter for Portable Application: Step-Up Series; LV Step Down Series; Inverting Series; Charge Pump Series
White-LED Drivers: LED Backlight; LED Lighting Solution

Glossary:

(1) VREF could be the minimum VOUT. In the application, VOUT depends on the designed external resistors. Please check with datasheets for more information.

(2) Internal Switch IOUT: built-in switch output current. ISW Limit: Internal switching current limitaMaximum IOUT can never exceed ISW limit. a Max. IOUT= (Efficiency)*(VIN/VOUT)*ISW

(3) External Switch IOUT: Possible external power switch IOUT. The external device driving capacity may change the IOUT value, possibly greater than the max. IOUT, shown in the table above. The real IOUT depend on the external device's driving capability. (BJT : b ; MOS : Gm)

Example:

If customers request a VIN=1.5V(Alkaline Battery) and minimum VIN=1.0V; VOUT=3.3V(IOUT=250mA); Low battery detective is needed. High efficiency (>90%) is needed. Solution: Choose AIC1620 for the solution
